Wire Wrapped Suction Strainer
Guangxing supplies external circumferential wedgewire suction strainers standard DIN 2501.
Strainer 10" Flanged Stainless Steel (316) Wire Wrapped Suction Strainer
Total suction area 4712 cm2, the open area 3026.4 cm2 (64.2%).
Blank SS316 casing pipe for the connection assembly.
Structure: External circumferential wedge wire screen, not perforated sheet.
Wedge wire screen material for strainers:
Height of the wedge wire: 3.65mm.
Typical slot size 10mm.
Standard followed:
Slot size 10mm and the connection flange dimensions are according to the standard DIN 2501, bolt circle PN10 for DN250.
